- Intelligent fan control
Fan speed is intelligently controlled to keep the GPU, memory, PWM IC and other components as low as possible in temperature to balance performance, and fan noise. - Precision fan control
Standard industry fans may have up to 10% difference between fan rotation cycles (RPM). The Fan IC Control on SAPPHIRE graphics cards reduce differential at approximately 3%. This up to 70% improvement on accuracy ensures that cooling and noise performance of every graphics card is up to scratch. - Robust VRM cooling
The SAPPHIRE graphics cards are designed with robust VRM cooling and have a high thermal conductivity pad on the backplate to take away the heat efficiently and effectively. - Robust memory cooling
A robust memory cooling solution has been integrated into each SAPPHIRE graphics card to cool down memory with a specially designed independent cooling module. - Backplate
The all-aluminum backplate provides additional rigidity that guarantees nothing bends and dust stays out. It also helps cool your card by increasing heat dissipation. - Two-ball bearing
These feature Dual Ball bearing fans, which have an approximately 85% longer lifespan than sleeve bearings in tests. - Fuse protection
In order to protect your card, the SAPPHIRE cards have fuse protection built into the circuit of the external PCI-E power connector to keep the components safe. - TriXX Boost
Take gaming to the next level by adjusting your resolution options. Gain FPS by slightly decreasing resolution that is then adjusted through image sharpening for a more immersive gaming experience with much more fine-grained control over the quality vs. performance tradeoff. - Power design
SAPPHIRE PULSE cards are designed with Phase Digital Power specifically for GPU and memory to aid in overclocking, balancing current distribution and averaging thermal dissipation for each power phase. - Free flow
The traditional axial fan design system circulates hot air to the fan inlet resulting in higher temperature.
|
Specifications |
| Product name: | SAPPHIRE PULSE RADEON RX 6600 GAMING 8GB GDDR6 HDMI / TRIPLE DP |
| Description: | Sapphire Pulse Radeon RX 6600 - Graphics card - Radeon RX 6600 - 8 GB GDDR6 - PCIe 4.0 - HDMI, 3 x DisplayPort |
| EAN: | 4895106290662 |
| Warranty: | 36 Months Bring-In Warranty |
| General |
| Device Type: | Graphics card |
| Bus Type: | PCI Express 4.0 |
| Graphics Engine: | AMD Radeon RX 6600 |
| Boost Clock: | 2491 MHz |
| Stream Processors: | 1792 |
| Process Technology: | 7 nm |
| VR Ready: | Yes |
| Max Resolution: | 7680 x 4320 |
| Max Monitors Supported: | 4 |
| Interfaces: | HDMI
3 x DisplayPort |
| API Supported: | DirectX 12 Ultimate |
| Features: | Dual Fan Design, UEFI BIOS, Intelligent Fan Control (IFC), FreeSync Technology, 2-slot Fan Cooler, metal wraparound backplate, Sapphire Dual-X Cooling Technology, fuse protection, Radeon VR Ready Premium, variable rate shading (VRS), Precision Fan Control, Radeon Image Sharpening, Radeon Anti-Lag, AMD FidelityFx, TriXX Boost, TriXX Supported, RDNA 2 Architecture, AMD Infinity Cache, DirectX Raytracing (DXR), AMD Smart Access Memory, Video Streaming up to 8K, Dual ball Bearing Fans |
| Memory |
| Size: | 8 GB |
| Technology: | GDDR6 SDRAM |
| Memory Speed: | 14 Gbps |
| System Requirements |
| OS Required: | Linux (64-bit), Microsoft Windows 7 / 8.1 / 10 (64 bit) |
| Min RAM Size: | 8 GB |
| Required Power Supply: | 500 W |
| Additional Requirements: | 8 pin PCI Express power connector |
| Miscellaneous |
| Power Consumption Operational: | 140 Watt |
| Software Included: | Sapphire TriXX, AMD Radeon Software |
| Width: | 4.005 cm |
| Depth: | 19.3 cm |
| Height: | 12.005 cm |
